How Furnace Size Is Measured: Input BTU vs Output BTU
Every gas furnace has two numbers on the rating plate. Input BTU is the fuel energy the burner pulls in. Output BTU is the heat that actually reaches your ducts. The gap between them is the AFUE rating, which is the seasonal efficiency in percent. A 100,000 BTU input furnace at 80 percent AFUE delivers 80,000 BTU per hour into the house. The other 20,000 BTU per hour goes up the flue as exhaust.
When you size a furnace, you start from heating load (the BTU per hour the house loses on the coldest design day) and work backward to input BTU. If your home loses 60,000 BTU per hour at 0°F, you need a furnace that outputs at least 60,000 BTU per hour. At 80 percent AFUE that means 75,000 BTU input. At 95 percent AFUE that means 63,200 BTU input. Same heat output, different fuel use.
The cheap shortcut some contractors use is "40 BTU per square foot for cold climates." A 2,000 sq ft house gets an 80,000 BTU output furnace by that math. The problem is that 40 BTU per sq ft is a 1970s number written before R-13 walls and double pane windows. A current code build with R-21 walls and R-49 attic insulation loses closer to 20 to 25 BTU per sq ft on a design day. Following the old rule gives you a 60 to 80 percent oversized furnace.
Furnace BTU by Square Footage and Climate Zone
The table below assumes average insulation (R-13 walls, R-30 attic), 8 foot ceilings, and a 70°F indoor setpoint. Output BTU is what the furnace actually delivers. To get input BTU divide output by your AFUE (0.80 or 0.95). The cold zones do most of the work because winter design temperature drops 30 to 50°F between Atlanta and Minneapolis.
| Home Size | Zone 2 (Mild) | Zone 3 to 4 (Mixed) | Zone 5 (Cold) | Zone 6 (Cold) | Zone 7 to 8 (Very Cold) |
|---|---|---|---|---|---|
| 1,000 sq ft | 25,000 BTU | 30,000 BTU | 35,000 BTU | 40,000 BTU | 45,000 BTU |
| 1,500 sq ft | 38,000 BTU | 45,000 BTU | 53,000 BTU | 60,000 BTU | 68,000 BTU |
| 2,000 sq ft | 50,000 BTU | 60,000 BTU | 70,000 BTU | 80,000 BTU | 90,000 BTU |
| 2,500 sq ft | 63,000 BTU | 75,000 BTU | 88,000 BTU | 100,000 BTU | 113,000 BTU |
| 3,000 sq ft | 75,000 BTU | 90,000 BTU | 105,000 BTU | 120,000 BTU | 135,000 BTU |
| 3,500 sq ft | 88,000 BTU | 105,000 BTU | 123,000 BTU | 140,000 BTU | 158,000 BTU |
These numbers are output BTU. Multiply by 1.25 to get the 80 percent AFUE input rating. Multiply by 1.053 to get the 95 percent AFUE input rating. A 2,000 sq ft zone 5 home needing 70,000 BTU output translates to 87,500 BTU input (80 percent) or 73,700 BTU input (95 percent). Most brands sell furnaces in 20,000 BTU input steps (40, 60, 80, 100, 120) so you round up to the next available size.
How Many Square Feet Does Each Furnace Size Heat?
A 60,000 BTU furnace at 80 percent AFUE heats about 1,600 square feet in a mixed climate and about 1,200 square feet in a cold one. An 80,000 BTU furnace covers roughly 2,150 and 1,600 square feet in the same two climates, and a 100,000 BTU furnace covers about 2,650 and 2,000. The number on the box is input BTU, so the first step is always to convert it to output.
The chart below does that conversion at 80 percent AFUE and then divides by the same heat loss per square foot used in the table above: 25 BTU in zone 2, 30 in zones 3 to 4, 35 in zone 5, 40 in zone 6, and 45 in zones 7 to 8. It assumes average insulation and 8 foot ceilings.
| Furnace Input | Output at 80% AFUE | Zone 2 | Zone 3 to 4 | Zone 5 | Zone 6 | Zone 7 to 8 |
|---|---|---|---|---|---|---|
| 40,000 BTU | 32,000 BTU | 1,300 sq ft | 1,050 sq ft | 900 sq ft | 800 sq ft | 700 sq ft |
| 45,000 BTU | 36,000 BTU | 1,450 sq ft | 1,200 sq ft | 1,050 sq ft | 900 sq ft | 800 sq ft |
| 60,000 BTU | 48,000 BTU | 1,900 sq ft | 1,600 sq ft | 1,350 sq ft | 1,200 sq ft | 1,050 sq ft |
| 70,000 BTU | 56,000 BTU | 2,250 sq ft | 1,850 sq ft | 1,600 sq ft | 1,400 sq ft | 1,250 sq ft |
| 75,000 BTU | 60,000 BTU | 2,400 sq ft | 2,000 sq ft | 1,700 sq ft | 1,500 sq ft | 1,350 sq ft |
| 80,000 BTU | 64,000 BTU | 2,550 sq ft | 2,150 sq ft | 1,850 sq ft | 1,600 sq ft | 1,400 sq ft |
| 90,000 BTU | 72,000 BTU | 2,900 sq ft | 2,400 sq ft | 2,050 sq ft | 1,800 sq ft | 1,600 sq ft |
| 100,000 BTU | 80,000 BTU | 3,200 sq ft | 2,650 sq ft | 2,300 sq ft | 2,000 sq ft | 1,800 sq ft |
| 110,000 BTU | 88,000 BTU | 3,500 sq ft | 2,950 sq ft | 2,500 sq ft | 2,200 sq ft | 1,950 sq ft |
| 120,000 BTU | 96,000 BTU | 3,850 sq ft | 3,200 sq ft | 2,750 sq ft | 2,400 sq ft | 2,150 sq ft |
A 95 percent AFUE furnace with the same input rating heats about 19 percent more floor area, because 95 divided by 80 is 1.19. A 60,000 BTU input furnace at 95 percent delivers 57,000 BTU and covers about 1,900 square feet in zones 3 to 4 instead of 1,600. A 75,000 BTU furnace at 95 percent delivers 71,250 BTU, enough for about 2,050 square feet in zone 5.
Treat these as ceilings for an average house. A home with poor insulation or single pane windows loses 20 to 25 percent more heat, so the same furnace covers less. A current code home loses 10 to 20 percent less. The calculator at the top of this page makes those adjustments for your house.
What Size Electric Furnace Do I Need?
Electric furnaces are sized in kilowatts. Take the heating load from the calculator above and divide by 3,412 to get kW. A home with a 51,000 BTU heating load needs a 15 kW electric furnace. A 68,000 BTU load needs 20 kW. There is no input versus output gap to work through, because nearly all of the electricity becomes heat inside the cabinet.
| Electric Furnace | Heat Output | Current at 240 Volts | Zone 2 | Zone 3 to 4 | Zone 5 | Zone 6 |
|---|---|---|---|---|---|---|
| 10 kW | 34,100 BTU | about 42 amps | 1,350 sq ft | 1,150 sq ft | 950 sq ft | 850 sq ft |
| 15 kW | 51,200 BTU | about 62 amps | 2,050 sq ft | 1,700 sq ft | 1,450 sq ft | 1,300 sq ft |
| 20 kW | 68,200 BTU | about 83 amps | 2,750 sq ft | 2,250 sq ft | 1,950 sq ft | 1,700 sq ft |
| 25 kW | 85,300 BTU | about 104 amps | 3,400 sq ft | 2,850 sq ft | 2,450 sq ft | 2,150 sq ft |
Check the electrical panel before you choose a size. A 20 kW furnace pulls about 83 amps at 240 volts on its own, which is more than a 100 amp service can spare once the range, dryer, and water heater are counted.
Running cost is the other half of the decision. At 16 cents per kWh, resistance heat costs about $47 per million BTU delivered. Natural gas at $1.20 per therm in an 80 percent furnace costs about $15 per million BTU delivered. That gap is why most all electric homes are better served by a heat pump, which moves 2 to 3 BTU of heat for every BTU of electricity it uses. The heat pump sizing calculator runs the same load from that side.
80 Percent vs 95 Percent AFUE: The Real Payback Math
The price difference between an 80 percent and a 95 percent furnace runs $1,000 to $2,500 installed in most US markets. The annual fuel savings depend on three things: heating degree days for your zip code, the price of natural gas in your state, and the size of the furnace.
Take a 2,000 sq ft Minneapolis home. Heating load is about 70,000 BTU output. Annual heating energy is roughly 850 therms at 80 percent AFUE, or 720 therms at 95 percent AFUE. At $1.20 per therm that is a $156 per year savings. With a $1,500 upgrade cost the payback is 9.6 years. Same house in Atlanta uses only 380 therms at 80 percent vs 320 at 95 percent. Savings drop to $72 per year and payback stretches to 20 years, which is past the typical 18 to 22 year furnace lifespan.
| City (Zone) | Annual Gas Use 80% | Annual Gas Use 95% | Savings / Year | Payback |
|---|---|---|---|---|
| Atlanta (3A) | 380 therms | 320 therms | $72 | 20+ years |
| St. Louis (4A) | 620 therms | 520 therms | $120 | 12 to 14 years |
| Chicago (5A) | 740 therms | 625 therms | $138 | 11 years |
| Minneapolis (6A) | 850 therms | 720 therms | $156 | 9 to 10 years |
| Duluth (7) | 980 therms | 820 therms | $192 | 8 years |
Two cases where 80 percent still wins. First, if your venting is an existing brick chimney and the install cost to add PVC sidewall venting for a 95 percent unit adds $800 to $1,500, the payback math gets worse. Second, if your gas service is propane instead of natural gas, the per BTU fuel cost is 2 to 3 times higher and the 95 percent payback drops to 4 to 6 years even in mild climates.
Single Stage, Two Stage, or Modulating: Which Furnace Type
Single stage furnaces fire at 100 percent every time the thermostat calls. In a mild climate where the furnace runs maybe 800 hours a year, the cycling is not a big problem. In a cold climate where the furnace runs 2,500 hours a year, the temperature swing between cycles is 4 to 6°F and you feel it. Install cost is the lowest, $3,500 to $5,500 for an 80 percent unit or $4,500 to $7,000 for a 95 percent.
Two stage furnaces have a low fire stage at about 65 percent capacity and a high fire stage at 100 percent. On a 35°F day in Chicago the unit runs on low fire for almost the whole heating call. High fire only kicks in below 15°F. Temperature swings drop to 1 to 2°F. Install cost runs $5,500 to $8,500 for 95 percent AFUE.
Modulating furnaces (also called variable capacity) ramp anywhere from 35 percent to 100 percent continuously. The blower is always ECM variable speed. The unit matches output to load almost perfectly, which means 30 to 60 minute run times instead of 5 to 10 minute cycles. Comfort is the best you can buy on a fossil fuel system. Install cost runs $7,500 to $11,000 for the furnace alone, and you usually want a communicating thermostat ($300 to $600) to actually use the modulation.
What Happens When Your Furnace Is the Wrong Size
Oversized furnaces are everywhere because the old rule of thumb (40 to 50 BTU per sq ft) was written for poorly insulated homes. A 120,000 BTU furnace on a house that needs 70,000 BTU runs in 4 to 6 minute bursts. The heat exchanger never reaches the steady state temperature where the AFUE rating applies, so the real seasonal efficiency drops 8 to 12 percent below the sticker number. The blower starts and stops 3 to 5 times more often than it should, which shortens motor life and increases startup electrical draw.
Comfort suffers in a less obvious way. A short burst of 120°F supply air hits the registers, then stops. The room overshoots the thermostat setpoint by 2 to 3°F, then drifts back down 3 to 4°F before the next call. The result is a noticeable warm then cool then warm pattern that most homeowners blame on drafts.
Undersized furnaces are rare but obvious. The unit runs continuously on a cold morning and the thermostat never catches up. Bedrooms at the end of the duct run sit 5 to 10°F below the thermostat reading. The other failure mode is a furnace that is correctly sized for the heat load but undersized for the duct system, which causes overheating and limit switch trips. The oversized HVAC problems article covers both sides of this in more detail.
How to Verify Furnace Size from a Contractor Quote
Most furnace quotes match the existing unit one for one. That is fine if the old furnace was the right size, but it almost never is. Before you sign anything, ask these four questions.
- Did you run a Manual J for heating? Most contractors run a Manual J for cooling because the AC quote depends on it. Fewer run one for heating. A heating Manual J needs your winter design temperature, the R-values of your walls and attic, your window U-factors, and an infiltration estimate. Ask for the printout.
- What winter design temperature did you use? Should be the ASHRAE 99 percent dry bulb for your zip code. Chicago is -2°F. Minneapolis is -11°F. Boston is 7°F. If they used "0°F for everywhere," the calculation is generic and probably oversized.
- Is this input BTU or output BTU? A "100,000 BTU furnace" is ambiguous. At 80 percent AFUE it outputs 80,000 BTU. At 95 percent AFUE it outputs 95,000 BTU. The quote should specify both numbers and which AFUE tier the unit is.
- Will the existing ductwork handle this furnace? A bigger furnace needs more airflow. If you go from a 60,000 BTU to a 100,000 BTU furnace on the same ducts, the supply air temperature spikes and the limit switch trips. The right answer is either Manual D duct calculations or a smaller furnace.
For a full load calc run from your end before the contractor visit, the residential load calculator walks through the heating side of Manual J. For background on what a real report looks like, the how to read a Manual J report guide explains the line items.
Frequently Asked Questions
What size furnace do I need for a 2,000 square foot home?
Most 2,000 square foot homes need 60,000 to 80,000 BTU of heat output, depending on climate zone and insulation. In a cold zone like Minneapolis (6A) you size toward 80,000 BTU output, which means a 100,000 BTU input furnace at 80 percent AFUE or an 84,000 BTU input furnace at 95 percent. In a mild zone like Atlanta (3A), the same house only needs about 50,000 BTU output, which is the smallest furnace most brands sell.
What size furnace do I need for a 1,000 square foot home?
A 1,000 square foot home needs about 30,000 BTU of heat output in a mixed climate (zones 3 to 4), 35,000 BTU in zone 5, and 40,000 BTU in zone 6. A 40,000 BTU input furnace at 95 percent AFUE delivers 38,000 BTU and covers the first two cases. In zone 6, step up to a 45,000 BTU furnace at 95 percent or a 60,000 BTU furnace at 80 percent.
What size furnace do I need for a 1,500 square foot home?
Plan on 45,000 BTU of output in zones 3 to 4, 53,000 BTU in zone 5, and 60,000 BTU in zone 6. In furnace sizes that is a 60,000 BTU input unit for a mixed climate at either efficiency. In zone 5, a 60,000 BTU furnace at 95 percent AFUE delivers 57,000 BTU and does the job. In zone 6, choose a 70,000 BTU furnace at 95 percent or an 80,000 BTU furnace at 80 percent.
What size furnace do I need for 2,500 to 3,000 square feet?
A 2,500 square foot home needs about 75,000 BTU of output in zones 3 to 4, 88,000 BTU in zone 5, and 100,000 BTU in zone 6. A 3,000 square foot home needs about 90,000, 105,000, and 120,000 BTU in the same three climates. At 95 percent AFUE that works out to furnaces of 80,000 to 110,000 BTU input for 2,500 square feet and 100,000 to 130,000 BTU input for 3,000. Most residential lines stop at 120,000 to 140,000 BTU, so large cold climate homes are often split across two systems.
How many square feet will an 80,000 BTU furnace heat?
At 80 percent AFUE an 80,000 BTU furnace delivers 64,000 BTU, which heats about 2,150 square feet in zones 3 to 4, 1,850 square feet in zone 5, and 1,600 square feet in zone 6. At 95 percent AFUE the same furnace delivers 76,000 BTU and covers about 2,550, 2,150, and 1,900 square feet. Those figures assume average insulation and 8 foot ceilings.
Can I size a furnace by zip code?
Your zip code matters because it sets your climate zone and winter design temperature, and those two numbers drive the heating load. Find your county in the climate zones guide, then pick the matching zone in the calculator above. Two homes of the same size 300 miles apart can need furnaces 20,000 BTU apart for that reason alone.
What is the difference between input and output BTU?
Input BTU is the fuel energy going into the furnace. Output BTU is the heat that actually makes it into your ducts. The ratio between them is the AFUE rating. A 100,000 BTU input furnace at 80 percent AFUE delivers 80,000 BTU of useful heat. The other 20,000 BTU goes up the flue. A 95 percent AFUE furnace at the same 100,000 input delivers 95,000 BTU. Always size by output, never by input.
Is 95 percent AFUE worth the extra cost over 80 percent?
In cold climates yes, in mild climates often no. A 95 percent furnace costs $1,000 to $2,500 more installed than an 80 percent. In Minneapolis with natural gas at $1.20 per therm, the upgrade saves about $250 to $400 per year and pays back in 5 to 8 years. In Atlanta the same upgrade saves $80 to $150 per year and pays back in 10 to 15 years, which is past the typical furnace lifespan. Run the numbers for your zip code before you decide.
Can a furnace be too big for my house?
Yes, and oversizing is the most common mistake in residential heating. A furnace 30 percent too big runs for 4 to 6 minute cycles, slams hot air into the ducts, and shuts off before the heat exchanger reaches steady state. Efficiency drops by 10 to 15 percent below the nameplate AFUE. The blower motor wears out years early. The right size runs for 12 to 20 minute cycles on a design day.
How long should my furnace run on a cold morning?
On a design temperature day (the coldest 1 percent of the year for your zip code), a correctly sized furnace runs in 12 to 20 minute cycles with maybe 5 to 10 minutes off in between. On a milder 30°F morning the cycles drop to 6 to 10 minutes on, 20 to 30 minutes off. If your furnace runs for 3 to 4 minutes and shuts off in any weather, it is oversized. If it cannot keep up with the thermostat on a 20°F night, it is undersized.
What does AFUE actually measure?
AFUE is annual fuel utilization efficiency. It is a seasonal average that includes steady state combustion, cycling losses, and standby pilot light losses. An 80 percent AFUE furnace burns 100 BTU of gas and delivers 80 BTU of useful heat across the heating season. AFUE does not measure electrical efficiency of the blower, which is why ECM blowers and variable speed motors matter on top of the AFUE number.
Should I get a single stage, two stage, or modulating furnace?
Single stage is fine in mild climates with short heating seasons (zone 3, 4 south of the Mason Dixon). Two stage is the right call for most of the cold US (zone 4 north through 6) because the low fire stage covers 70 percent of winter hours and the high fire only kicks in on the coldest days. Modulating (10 percent to 100 percent continuous) is worth the $1,500 to $3,000 upgrade in very cold zones (6B, 7, 8) and in tight high performance homes where comfort matters more than dollar payback.
How is furnace BTU different from AC BTU?
A furnace and an AC sit on opposite ends of the same duct system but they size differently. The furnace handles winter sensible heat loss through walls, windows, and infiltration. The AC handles summer sensible heat gain plus latent humidity. A 2,000 sq ft house in Chicago might need 60,000 BTU of heating but only 30,000 BTU (2.5 ton) of cooling. The same house in Houston might need 50,000 BTU of heating but 48,000 BTU (4 ton) of cooling. Always size each separately.
Do I need to replace my AC if I upgrade my furnace?
Not always, but the indoor coil sitting on top of the furnace is matched to a specific AC outdoor unit. If the AC is 12 years old or older, replacing it with the furnace is usually cheaper than paying labor twice. If the AC is under 8 years old and using the same refrigerant (R-410A or R-454B), you can keep it and swap just the furnace. The coil cabinet has to fit the new furnace flange, which sometimes requires a transition piece.
What about a heat pump instead of a furnace?
In zones 1 through 4 a heat pump is almost always the better choice on operating cost. In zones 5 and 6 a dual fuel setup (heat pump above 30°F, furnace below) often wins. In zones 7 and 8 a furnace or boiler still beats most heat pumps below 0°F unless you spec a cold climate heat pump rated for 5°F operation. The heat pump sizing calculator walks through the same load math from the heat pump side.
